Overview
AJ4309 | 2019-08-13 2–3
Battery
Item Description Notes
A DC jack Not used
B Ethernet port For service
C Detector indicator Detector indicator of control panel
D Power button Power button of control panel
E Mode button Mode switch
F Antenna
Item Description Notes
A Battery label
B Battery interface 8 pin battery connector
C Pilot pin
D Indicator Installation direction indicator
