Overview
2–4 AJ4309 | 2019-08-13
Battery Charger
Battery Charger Indicator
Item Description Notes
A Battery Interface A 8 pin battery connector
B Battery Interface B Not used
C Battery Interface C Not used
D Indicator The indicator definition is as follow
E The limit ball plug /
F Hand Pull Position /
G AC Jack 220V (ac) input
Item Name
APower Indicator
B Charging Indicator
C Charge Full Indicator
