Carlisle BINKS E4-100 - Page 19

EN
KEY
(Reverse for assembly)
LOCTITE
TORQUE
MAINTENANCE ORDER
GREASE INTERNAL
(AGMD-010)
GREASE
(ITEM19)Whenfittingnewbearings:
Ensuresealshavebeenremovedfrominsideof
bearingtoensureacorrectgreasesupplypathvia
centrespacer.
(ITEM8)Tightenonfinal
assemblytogivecorrect
orientationforhoseconnection
togreasenipple.
(ITEM19)Orientatebearingsoblacksection
alongthebodyis
alignedtotheblock'sside.
