11
ENGLISH
Connections
In order to select the desired range (LDI35.AV0), jumper, if necessary,
between the relevant screw terminals.
Connect LDI35.AV0 (voltmeter or ammeter) as shown in the figure.
Attention: the voltmeter input is to be connected in parallel to the source
to be measured.
Attention: the ammeter input is to be connected in series to the source
to be measured.
LDI35.AV2
LDI35.AV0
