15
ENGLISH
the front cover by inserting it first in the lower part and then in the upper
part of the locking system.
OPERATING MODE
• Power-on
When you switch the unit on, the instrument shows for approximately 5
seconds the instruments’s software revision, for example: r.1.
• Displaying, control (if present) and diagnostics
The instrument shows continuously the value of the input variable as
defined in the programming phase.
The value shown on the display is continuously compared with the value
of the set-point and of the other parameters, thus generating the control
function by energizing/de-energizing the output relay.
• Programming
This phase is identified by the blinking of the decimal point on the right
side of the display.
To enter the programming phase, press the
S
key until “PAS” is
shown on the display; then “0” is displayed: the correct numerical code
(password) is to be entered. The following conditions may occur:
• 1) the operator hasn’t entered any Password: press the
S
key again
to enter the configuration menus of the instrument;
