POWER SUPPLY INPUT
230 VAC -15% +10% 50/60 Hz (standard);
115 VAC -15% +10% 50/60 Hz (on request);
240 VAC -15% +10% 50/60 Hz (on request);
120 VAC -15% +10% 50/60 Hz (on request);
48 VAC -15% +10% 50/60 Hz (on request);
24 VAC -15% +10% 50/60 Hz (on request);
Insulation: 4000 VRMS between power supply input and all the other
inputs/outputs;
9 to 32 VDC, G.I., max. starting current: ≤1.2A/200 ms (on request);
40 to 150 VDC, G.I., max. starting current: ≤0.6A /200 ms (on request);
Insulation: 500 VRMS between power supply input and all the other inputs/
outputs;
Self-consumption: 6.5 VA.
OPERATING TEMPERATURE
From 0 to +50°C (R.H. < 90% non-condensing)
STORAGE TEMPERATURE
From -10 to +60°C (R.H. < 90% non-condensing)
STABILITY OF ACCURACY
6 months
REFERENCE VOLTAGE FOR THE INSULATION
300 VRMS to earth
