4
ENGLISH
TEMPERATURE DRIFT (LDI35.CF: RTD / TC / )
± 200 ppm/°C.
SAMPLING RATE
LDI35.AV0: 4 times/second, dual slope 16 bits A/D converter
LDI35.AV2: 2 times/second, dual slope 16 bits A/D converter
LDI35.CF temperature measurement: 2 times/second, dual slope
16 bits A/D converter
DISPLAY
7-segment LED, h 14.2 mm; 3
1
/
2
digits or 3 digits + dummy zero.
MAXIMUM INDICATIONS
LDI35.AV0: 3
1
/
2
digit: 1999; 3 + 0 digit: 9990;
LDI35.AV2: 3
1
/
2
digit: 1999 (DC/AC); 3 + 0 digit: 9990 (DC/AC);
LDI35.CF: temperature: depending on the range and on the type of
probe; resistance: 199.9 (STD) / 1999 (on request).
MINIMUM INDICATIONS
LDI35.AV0: 3
1
/
2
digit: -1999; 3 + 0 digit: -1990;
LDI35.AV2: 3
1
/
2
digit: -1999 (DC), 0 (AC); 3 + 0 digit: -1990 (DC), 0 (AC).
LDI35.CF: temperature: depending on the range and on the type of
probe; resistance: 0.
MEASUREMENT (VOLTAGE / CURRENT)
LDI35.AV0: DC voltage/current.
LDI35.AV2: DC voltage/current and AC voltage/current (measurement
