10
ENGLISH
INSTALLATION
Overall dimensions and panel cut-out
(all quotes are expressed in mm)
A
A
A
A
A
A
A
A
A
A
A
A
A
91 mm
75 mm
max. 10
mm
83 mm
AAAAAAAA
A
AAAAAA
A
A
AAAAAA
A
A
AAAAAA
A
AAAAAAAA
92 mm
45 mm
F
96 mm
48 mm
S
Mounting
Insert the instrument into the panel and fasten it by fixing the two lateral
brackets (1) supplied with the instrument to the appropriate location (2).
A
A
A
A
A
A
1
2
2
