18
ENGLISH
Lo.E : programming of the min. value of the electrical scale (see table
“inP” in the flow chart). Enter the minimum value that is to be measured
(zero scale).
Hi.E : programming of the max. value of the electrical scale (see table
“inP” in the flow chart). Enter the maximum value to be measured (full
scale).
NOTE: in the resistance measurements (“inP” ⇒ “rtd” ⇒ “r5”) the
maximum electrical full scale to be entered is: “1999” and the corre-
sponding value of “Hi” must be “199.9” in order to take resistance
measurements with a 0.1Ω resolution.
NOTE: if the measured variable goes beyond the scale limits “Lo.E”/
”Hi.E”, the value displayed during the measuring phase will be blinking
and updated with reference to the measured value up to the maximum
displaying range (“dC” and temperature measurements: -1999/1999;
“AC” and resistance measurements: 0/1999).
d.P : selection of the decimal point position in the “Hi-Lo” scale.
Lo : programming of the min. value of the displayed scale. Enter the
value to be displayed in correspondence with the minimum value of the
electrical scale “Lo.E”.
Example: “Lo.E”=4.00 mA ⇒ “Lo”=100 mbar, means that when the value
measured by LDI35 is 4 mA, the displayed value will be 100 mbar.
Hi : programming of the max. value of the displayed scale. Enter the
value to be measured in correspondence with the maximum value of the
electrical scale “Hi.E”. Example: “Hi.E”=19.99 mA ⇒ “Hi”=1800 mbar,
means that when the value measured by LDI35 is 20 mA, the displayed
value will be 1800 mbar.
NOTE: electrical scale and displayed scale must have:
