Page #6 background image
6
ENGLISH
INPUTS (RTD TEMPERATURE / )
CFX: RTD, Pt100, range: -200 °C / -328 °F to +850 °C / 1562 °F
CFX: RTD, Ni100, range: -60 °C / -76 °F to +180 °C / 356 °F
CFX: , 200.0 , range: 0 to 199.9
CFP: RTD, Pt1000 range: -200 °C / -328 °F to +850 °C / 1562 °F
CFP: , 2000 range: 0 to 1999
Other inputs are available by acting on the scaling parameters.
INPUTS (TC TEMPERATURE)
CFX/CFP: TC-J, range: -50 °C / -58 °F to +760 °C /+1400 °F
CFX/CFP: TC-L, range: -50 °C / -58 °F to +760 °C / +1400 °F
CFX/CFP: TC-K, range: -200 °C / -328 °F to +1260 °C / +1999 °F
CFX/CFP: TC-S, range: +350 °C / +1750 °C
CFX/CFP: TC-T, range: -200 °C / -328 °F to +400 °C / +752 °F
Other inputs are available by acting on the scaling parameters.
COMPENSATION (RTD/)
For 3-wire connections, line resistance up to 10 .
COMPENSATION (TC)
Cold junction, within a temperature range from 0 to 50 °C of ambient
temperature.
ALARM SET-POINTS
0 (standard) 1 (on request).
Alarm type: the alarm is active only for under/over-range, high alarm, low
alarm, low alarm with disabling at power-on, high alarm with latch, low
