BRx7 User Manual
Ports and Connecons
All ports and connecons are located on the boom of the unit, as shown
in Figure 2‐1. Table 2‐1 provides addional informaon about each port/
connecon.
Figure 2‐1: BRx7 ports and connectors
Table 2‐1: BRx7 ports and connecons
Ports and
Connecons
Main Kits What to connect
7‐pin Diagnosc Port (LEMO) Diagnosc cable for serial or USB
5‐pin Power/Data Port (LEMO) External Power, data, and radio devices
UHF Antenna Connector External UHF antenna
Mounng hole Pole or tripod mount
5/8” Mounng hole
Audio Speaker
UHF Antenna Connector
7‐pin Diagnosc Port
5‐pin Power/Data Port
