BRx7 User Manual
Installing the BRx7 on a Tribrach
Installing UHF Antennas
To install the external UHF antenna of the BRx7, locate the UHF antenna
(8030.042.007) from the kit list under What’s Included in Your Kit.
Insert the connector end of the UHF antenna and rotate clockwise to
secure the antenna to the BRx7.
Installing UHF
Antennas
The BRx7 mounts ush to the tribrach by securing the 5/8‐11” female
metal mounng poron of the BRx7 to the standard 5/8‐11” male poron
of the tribrach. Hand‐ghten (35‐40 in‐lbs. of torque) to secure the BRx7
onto the mount in a clockwise rotaon.
Installing the
BRx7 on a
tribrach
Figure 2‐6: Installing BRx7 on a tribrach
