Installing the BRx7 on a Range Pole
Use the standard 5/8‐11” mount on the boom of the BRx7 to secure the
unit to a eld standard 5/8‐11” range pole.
The BRx7 should be placed carefully on the range pole to ensure cross‐
threading does not occur while rotang the unit in a clockwise direcon.
Hand‐ghten (35‐40 in‐lbs. of torque) to secure the unit.
Installing the
BRx7 on a
range pole
Figure 2‐7: Range pole installaon
