BRx7 User Manual
Installing/Connecng the BRx7
Press the buon on the side to open the baery compartment and remove
the door as shown in Figure 2‐3.
Place the baery into the compartment. Take care to ensure the contacts
on the baery are on the same side as the contacts on the receiver. The
baery will t down onto the notch. Slide the baery forward unl it clicks
and locks into place (Figure 2‐4).
Installing
baeries
Installing
baeries
Figure 2‐4: Installed baery
Figure 2‐3: Baery compartment door removed
