Troubleshoong (connued)
Troubleshoong
Issue
BRx7 will not go RTK Fixed
Possible Resoluon
• If the BRx7 is “RTK Float” then it is
receiving RTK or Atlas correcons.
• If the RTK latency is between 10‐15
seconds, these are most likely Atlas
correcons.
• If the RTK latency is less than 10‐15
seconds, the BRx7 is receiving RTK, but
probably will not Fix because of the
environment.
• If the BRx7 will not go RTK Float or RTK
Fixed, check to ensure the base staon
is operang.
• Verify the sengs of the UHF radio at
the base and at the rover are the same.
• If using a network, check the Cellular
Signal Quality (CSQ) under the Informa-
on tab for cellular recepon.
• If using the internal UHF radio, ensure a
valid 400 MHz or 900 MHz UHF antenna
is plugged into the TNC connector.
If using Bluetooth, ensure RTK is reaching
the data collector (check the data collec-
tor internet or data collector radio).
