Carlton 3500D - Hydraulic Assembly

3500D HYDRAULIC ASSEMBLY
68
REMOTE CONTROL HYDRAULIC ASSEMBLY
ITEM NO PART NO DESCRIPTION QTY
1 0300150A Valve Manifold Assembly 1
2 0300142 Hydraulic Pump 1
3 0300105G Tongue Cylinder - 3 x 48 1
4 0300105E Lift Cylinder - 3 x 10 1
5 0300105D Swing Cylinder - 3 x 8 2
6 0300135C Filter Head 1
7 0300135 Filter Element - 10 Micron 1
8 0300220 3/4 mp-mp 90 1
9 0300218 3/4 mp-jic 90 1
10 0300234 3/4 jic-orb 1
11 0300245 1/2 mp-5/8 orb 90 1
12 0300205 3/8 orb-jic 90 1
13 0300236 1/2 orb-jic 1
14 0300217 1/2 jic-3/4 mp 90 1
15 0300237 3/8 orb-jic 8
16 0300215 3/8 jic-1/2 mp 90 7
17 0300238 3/8 jic-1/2 mp 1
18 0300239 1/4 orb plug 5
19 Hose Assembly - 3/8 x 22” 1
20 Hose Assembly - 3/8 x 31” 1
21 Hose Assembly - 3/8 x 53” 2
22 Hose Assembly - 3/8 x 80” 2
23 Hose Assembly - 3/8 x 90” 1
24 Hose Assembly - 3/8 x 73” 1
25 Hose Assembly - 1/2 x 86” 1
26 Hose Assembly - 1/2 x 98” 1
27 Hose Assembly - 3/4 x 21” 1
