Carlton 3500D - FRAME ASSEMBLY; BASE FRAME ASSEMBLY

3500D FRAME ASSEMBLY
77
BASE FRAME ASSEMBLY
ITEM NO PART NO DESCRIPTION QTY
1 3500145 Frame Weldment 1
2 0550208 Grease Seal 2
3 0550209 Inner Bearing Cone 2
4 0550210 Inner Bearing Cup 2
5 0550212 Hub 2
6 0550010 Tire Assembly 2
7 0550213 Bearing Cup 2
8 0550214 Bearing Cone 2
9 0550215 Spindle Washer 2
10 0550217 Tang Washer 2
11 0550216 Spindle Nut 2
12 0550218 Grease Cap 2
13 3500142 2” BullDog Hitch 1
14 3500143 2 5/16” BullDog Hitch 1
15 3500144 3” Pintle Hitch 1
16 3500145 2 1/2” Pintle Hitch 1
17 0550004 Trailer Jack 1
18 0200001 Fuel Tank - 16 gal. 1
19 0200002 Tank Strap 2
20 3500165 Deck Plate - R/H 1
21 3500166 Deck Plate - L/H - Remote 1
22 3500177 Front Chip Guard 1
23 3500191 Chip Guard Front Bracket 2
24 3500192 Chip Guard Side Bracket 3
25 0150117 3/8-16 x 1 Carriage Bolt 32
26 0150303 3/8 Flat Washer 34
27 0150207 3/8 Lock Nut 34
28 3500114 Pan Guard 1
29 0150133 3/4-10 x 2 HCS 2
30 0150307 3/4 Flat Washer 2
31 0150211 3/4-10 Lock Nut 2
32 3500216 Fender - R/H 1
33 3500217 Fender - L/H 1
34 0150304 1/2 Flat Washer 4
35 0150206 1/2-13 Lock Nut 4
36 3500259 Fuel Pick-up Tube - 16 Gal 1
37 0300249 3/8 MP Plug 1
38 0300302 5/16” Fuel Line 94”
39 0150707 5/16” Clamp 4
40 3500262 Deck Plate - L/H - Swing Out 1
41 0350034 Battery Box 1
42 0350035 Battery Box Strap 1
43 0150508 Battery Bracket 1
44 0200138 In-Line Fuel Filter 1
45 3500178 Front Pan Chip Guard 1
46 3500179 Side Pan Chip Guard 2
47 3500265 Pan Chip Guard Bracket 2
48 0150605 Hitch Pin - 3/4 x 7 1
49 0550102 Lug Nut 10
