Carlton 3500D - HYDRAULIC ASSEMBLY; REMOTE CONTROL HYDRAULIC ASSEMBLY

3500D HYDRAULIC ASSEMBLY
71
SWING OUT CONTROLS HYDRAULIC ASSEMBLY
ITEM NO PART NO DESCRIPTION QTY
1 0300130 Hydraulic Control Valve 1
2 0300142 Hydraulic Pump 1
3 0300105G Tongue Cylinder - 3 x 48 1
4 0300105E Lift Cylinder - 3 x 10 1
5 0300105D Swing Cylinder - 3 x 8 2
6 0300135C Filter Head 1
7 0300135 Filter Element - 10 Micron 1
8 0300257 1/2 orb-3/8 jic 4
9 0300236 1/2 orb-jic 2
10 0300258 1/2 orb-3/8 fp sw 2
11 0300223 3/8 mp-fp-fp tee 2
12 0300210 3/8 mp-jic 2
13 0300225 3/8 mp-fpsw 1
14 0300240 3/8 mp-mp nipple 1
15 0300137 Needle Valve 1
16 0300122A Valve Body - XEB 1
17 0300120 Cartridge Valve - LHN 3
18 0300214 3/8 mp-jic 90 4
19 0300259 3/8 mp-jic-jic tee 2
20 0300215 3/8 jic-1/2 mp 90 6
21 0300231 1/2 mp-3/8 mp 1
22 0300122 Valve Body - ECB 1
23 0300213 1/4 mp-3/8 jic 90 1
24 0300224 1/2 mp-fp-fp tee 1
25 0300209 1/2 mp-mp nipple 1
26 0300260 Orifice - .187 1
27 0300217 1/2 jic-3/4 mp 90 1
28 0300220 3/4 mp-mp 90 1
29 0300218 3/4 mp-jic 90 1
30 0300234 3/4 orb-jic 1
31 0300235 5/8 orb-1/2 jic 90 1
32 Hose Assembly - 3/4 x 17” 1
33 Hose Assembly - 1/2 x 139” 1
34 Hose Assembly - 1/2 x124” 1
35 Hose Assembly - 3/8 x 11” 1
36 Hose Assembly - 3/8 x 89” 1
37 Hose Assembly - 3/8 x 85” 1
38 Hose Assembly - 3/8 x 8” 1
39 Hose Assembly - 3/8 x 88” 1
40 Hose Assembly - 3/8 x 86” 1
41 Hose Assembly - 3/8 x 111” 1
42 Hose Assembly - 3/8 x 127” 1
43 Hose Assembly - 3/8 x 80” 1
44 Hose Assembly - 3/8 x 73” 1
45 Hose Assembly - 3/8 x 32” 1
46 Hose Assembly - 3/8 x 24” 1
