Revised 3.15.05
SERIAL NUMBERS
OWNER DOMAIN
J.P. CARLTON COMPANY DIV. DAF INC.
STUMPCUTTERS
4 BOOM ASSEMBLY
DESCRIPTION
ISSUE
R1
35HP VANGUARD POLY CHAIN ASSEMBLY
DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
BUSINESS LINE
FUNCTION GROUP
PART ITEM DESCRIPTION QTY
1 0250115A PC Sprkt 8M-40S-62 Taper Lock 2
2 0250115F1 2012 1 11/16" Taper Lock Bshn 2
3 0250212 BUSHING,QD INERCHANGEABLE,SF 1-11/16 1
4 0250321 SHEAVE 1
5 0400112 POLYCHAIN 2300 2500 SP4012 1
6 0500113 BEARING,CUTTER WHEEL 2
7 10D-0828 BOLT,SQ. HEAD,1/2"-13 X 3-1/2" UNC GR8 1
8 10D-0832ZI SQUARE HEAD BOLT,1/2-13 x 4 UNC GR 8 2
9 10G-0608 CARRIAGE BOLT 3/8-16 x 1 UNC GR 8 6
10 12A-0508 HEX C/S 5/16-18 x 1 UNC GR 5 4
11 12A-0616 HEX C/S 3/8-16 x 2 UNC GR 8 3
12 12A-1020ZI HEX C/S 5/8-11 x 2-1/2 UNC GR 8 Z&Y 4
13 12D-0712 SOC HD C/S 7/16-14 X 1-1/2 UNC GR 8 BLCK 4
14 12S-0506ZI SERRATED FLANGE HEX C/S 5/16-18 x 3/4 UNC GR 5 6
15 14020017 COVER,JACK SHAFT BEARING,BRIGGS 1
16 14040024 WELDMENT,POLY CHAIN GUARD,BACK 1
17 14040025 WELDMENT,POLY CHAIN GUARD,COVER 1
18 14040034 WELDMENT,POLY CHAIN ENDCAP 1
19 14040133 SHAFT,JACK SHAFT,1-11/16,VANGUARD 1
20 29A-08 NUT,STOVER LOCK, 1/2-13 UNC GR8 6
21 30A-06 LOCKWASHER, 3/8" USS GR8 3
22 30A-08ZI LOCK WASHER,1/2" USS GR8 Z&Y 3
23 31A-10ZI FLAT WASHER 5/8 USS GR 8 NARROW Z&Y 4
24 70A-0614 KEY ,3/8 SQ. 1-3/4" LONG 1
25 70A-0618 KEY,3/8 SQ. 2-1/4" LONG 1
34
To Next Page
