Revised 3.15.05
SERIAL NUMBERS
OWNER DOMAIN
J.P. CARLTON COMPANY DIV. DAF INC.
STUMPCUTTERS
2 VALVE BOX/ENGINE/ELECTRICAL
DESCRIPTION
ISSUE
R2
REMOTE VALVE HYD, RETURN ASSEMBLY
DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
BUSINESS LINE
FUNCTION GROUP
7
PART ITEM DESCRIPTION QTY
1 0300121L Manifold- SP5014TRX Sun 1
2 0300135E HYD. IN-TANK FILTER STF 1
3 0300135F HYD. IN-TANK FILTER ELEMENT 1
4 0300266A HYD. SITE GAUGE W/TEMP 1
5 0300236 1/2 JIC-1/2 PRB-6400-8 1
6 0300245A 1/2 JIC-3/4ORB-6400-8-12 1
7 13D-0612 SHCS 3/8X1-1/2 NC GR8 2
8 30A-06ZI 3/8 LOCK WASHER 2
9 31A-06ZI 3/8 FLAT WASHER 2
10 HSP5014R13 HOSE ASSEMBLY 1
11 14010020 WELDMENT,HYD. TANK 1
12 0300169 STRAINER-TANK MOUNTED LTM-15 1
13 HSP5014R16 HOSE ASSEMBLY 1
14 0300165BR1 Hydraulic Oil Cooler- 1
7
8
9
2
6
3
4
11
1
5
12
10
13
14
