Revised 3.15.05
SERIAL NUMBERS
OWNER DOMAIN
J.P. CARLTON COMPANY DIV. DAF INC.
STUMPCUTTERS
2 VALVE BOX/ENGINE/ELECTRICAL
DESCRIPTION
ISSUE
R2
MANUAL VALVE BLADE HYD, ASSEMBLY
DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
BUSINESS LINE
FUNCTION GROUP
17
PART ITEM DESCRIPTION QTY
1 0300377 Control Valve 5014TRX Manual 1
2 0300105A HYDRAULIC CYLINDER 1
3 0300257 3/8 JIC- 1/2 ORB-6400-6-8 2
4 1/2" O-RING-3/8" JIC 90DEG 2
5 HSP501412 Hose Assembly 1
6 HSP501413 Hose Assembly 1
3
5
6
2
4
1
