Revised 3.15.05
SERIAL NUMBERS
OWNER DOMAIN
J.P. CARLTON COMPANY DIV. DAF INC.
STUMPCUTTERS
1 FRAME AND TANKS
1
DESCRIPTION
ISSUE
R1
ASSY,GAS FUEL TANK
DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
1J9BH1230C1167041
BUSINESS LINE
FUNCTION GROUP
9
7
2
3
4
5
6
PART ITEM DESCRIPTION QTY
1 0200210 GAUGE,SPIRAL FUEL,21" 1
2 0201001 FUEL CAP,NON-VENTED 1
3 0201002 CHARCOAL CANISTER 1
4 0201002A VALVE,SLOSH 1
5 0201002B GROMMET,ROLL OVER VALVE 1
6 0201002C MOUNT,CARBON CANISTER 2
7 0350016B Black Wire Tie - 14 1/2" 2
8 14010028 WELDMENT,FUEL TANK,GAS 1
9 14010036 WELDMENT,PICK-UP TUBE 1
1
8
