Revised 3.15.05
SERIAL NUMBERS
OWNER DOMAIN
J.P. CARLTON COMPANY DIV. DAF INC.
STUMPCUTTERS
2 VALVE BOX/ENGINE/ELECTRICAL
DESCRIPTION
ISSUE
R1
REMOTE VALVE GAS HYD, INLET ASSEMBLY
DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
BUSINESS LINE
FUNCTION GROUP
9
PART ITEM DESCRIPTION QTY
1 0300121K Manifold 4012 A308 149 C03 1
2 0300142G Hyd Pump 4012- Bucher 1
3 0300354J1 3/4NPT - 3/4 FJ45T 1
4 3/4 JIC -1/2 ORB - 6400-12-8 1
5 0300219 1/2 JIC - 1/2 ORB 90 - 6801-8 1
6 0300236 1/2 JIC-1/2 ORB- 6400-8 1
7 HSP5014R17 Hose Assembly 1
8 HSP5014R18 Hose Assembly 1
7
3
1
6
4
2
5
8
To Next Page
