SP5014TRX SERVICING HYDRAULICS
52
SAFETY
NEVER SERVICE A MACHINE WITH THE ENGINE RUNNING, SEVERE
PERSONAL INJURY COULD OCCUR. TURN ENGINE OFF THEN REMOVE
IGNITION KEY AND DISCONNECT POSITIVE BATTERY CABLE TO AVOID
STARTING MACHINE ACCIDENTALLY.
CUTTER WHEEL MUST BE DISENGAGED BEFORE TURNING ENGINE
ON/OFF AND BEFORE SERVICING A MACHINE. OTHERWISE SEVERE
PERSONAL INJURY COULD OCCUR AS WELL AS MACHINE DAMAGE.
ALL MACHINE PARTS MUST COME TO A COMPLETE STOP AND HAVE
TIME TO COOL COMPLETELY BEFORE SERVICING A MACHINE OR
SEVERE INJURY COULD OCCUR, POSSIBLY SERIOUS BURNS AND/OR
DISMEMBERMENT.
PLACE THE CUTTER WHEEL ON THE GROUND WHEN PERFORMING
SERVICE ON A MACHINE.
RELEASE HYDRAULIC PRESSURE BEFORE PERFORMING ANY SERVICE
TO HYDRAULIC LINES OR OTHER COMPONENTS.
FLUID UNDER PRESSURE CAN PENETRATE THE SKIN AND CAUSE SEVERE
INJURY. SEEK IMMEDIATE MEDICAL ATTENTION IF SKIN IS
PENETRATED. CHECK HOSES AND FITTINGS USING A BOARD OR
CARDBOARD; DO NOT USE HAND OR FINGER. ALWAYS WEAR EYE
PROTECTION.
HYDRAULIC OIL & FILTER
Check hydraulic oil level daily. This
Carlton stump grinder is equipped with a
gauge that shows the level of oil and the
temperature of the oil. When filling the tank
2/3 with oil, the window of the gauge will
also fill with oil, as the level gets higher in
the tank. Never fill the oil tank above the
BLACK line at the top of the gauge. Do not
run the machine with the oil level below the
RED line at the bottom of the gauge.
The machine is equipped with Citgo AW46
hydraulic oil at the time of manufacture.
Use the same or equivalent. NOTE: If
machine is ran in extreme climates you may
need to adjust the weight of the oil for the
machine to operate properly.
