SP5014TRX SERVICING BEARINGS
44
Replacing Cutter Wheel Bearings
Take out the three bolts that hold the bushing
to the cutter wheel and place them in the
empty threaded holes on the bushing and
tighten slowly. This will push the bushing
out of the cutter wheel. Remove bushing and
cutter wheel.
Place cutter wheel, bushing and bearings
back on new shaft. Place back up under
machine and lower boom box on to bearings.
NOTE: To make shaft installation easier, place shaft in a freezer for approximately one hour or
overnight if possible. This will shrink the shaft and make installation into the new bearings
much easier.
Bolt bearings and cutter wheel back to boom
box and tighten bolts down.
