Revised 3.15.05
SERIAL NUMBERS
OWNER DOMAIN
J.P. CARLTON COMPANY DIV. DAF INC.
STUMPCUTTERS
2 VALVE BOX/ENGINE/ELECTRICAL
DESCRIPTION
ISSUE
R2
MANUAL VALVE HYD, STEERING ASSEMBLY
DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
BUSINESS LINE
FUNCTION GROUP
15
PART ITEM DESCRIPTION QTY
1 0300377 Control Valve 5014TRX Manual 1
2 0400249F Motor- Eaton 2
3 0300257 3/8 JIC- 1/2 ORB - 6400-6-8 2
4 1/2" O-Ring - 3/8” JIC 90 2
5 HSP501409 Hose Assembly 1
6 HSP501406 Hose Assembly 1
7 HSP501408 Hose Assembly 1
8 HSP501407 Hose Assembly 1
9 HSP501404 Hose Assembly 1
10 HSP501405 Hose Assembly 1
11 HSP501421 Hose Assembly 1
12 HSP501422 Hose Assembly 1
13 HSP501402 Hose Assembly 1
14 HSP501403 Hose Assembly 1
15 0300127A1 44-4 Swg Mnfld with Ndle Cvty 1
To Next Page
