47
Table 27 — Medium Temperature Motor Data
LEGEND
NOTES:
1. Please contact Carlyle Application Engineering for proper motor pro-
tection device.
2. Delta wiring is not applicable for the selected voltage.
COMPRESSOR
BASE MODELS
MOTOR SIZE
(HP AT
60 Hz)
MOTOR
VOLTAGE
(VOLTS-PH-FREQ)
RLA LRA
404A 407A 407C 407F 507A 448A 449A WYE DELTA
06TSM137 75
460-3-60
123 110 104 150 129 113 101 174 545
400-3-50
111 91 86 99 113 102 84 170 530
690-3-50
65 52 50 57
66 60 48 306 NOTE 1
575-3-60
99 91 86 126 108 91 84 139 436
380-3-60
149 139 131 190 163 137 128 211 660
690-3-60
82 73 70 100 87 75 67 381 NOTE 1
230-3-60
223 191 183 209 240 205 176 340 1060
200-3-50
246 218 207 299 257 226 201 348 1090
200-3-60
283 261 249 360 310 260 240 400 1254
06TSM155 75
460-3-60
126 103 98 155 120 116 89 174 545
400-3-50
118 95 92 129 118 109 80 170 530
690-3-50
68 48 46 65 60 63 47 306 NOTE 1
575-3-60
101 95 91 144 111 93 71 139 436
380-3-60
152 141 135 212 165 140 108 211 660
690-3-60
84 75 71 112 86 77 60 381 NOTE 1
230-3-60
235 181 174 245 224 216 161 340 1060
200-3-50
252 225 215 338 262 232 178 348 1090
200-3-60
290 271 258 406 315 267 205 400 1254
06TTM266 150
460-3-60
228 215 205 287 234 210 198 382 1190
400-3-50
216 195 188 251 218 199 179 388 1210
690-3-50
125 112 108 145 126 115 103 699 NOTE 1
575-3-60
183 180 173 241 197 168 166 306 952
380-3-60
276 271 260 363 296 254 249 462 1441
690-3-60
152 149 143 200 163 140 137 832 NOTE 1
230-3-60
433 408 393 529 459 398 375 776 2420
20
0-3-50
456 428 410 572 468 420 394 764 2380
200-3-60
525 516 494 690 564 483 475 879 2737
06TTM301 150
460-3-60
228 216 210 270 233 210 183 382 1190
400-3-50
217 198 192 233 219 200 170 388 1210
690-3-50
126 114 111 136 127 116 98 699 NOTE 1
575-3-60
183 182 176 228 197 168 146 306 952
380-3-60
276 273 265 342 295 254 221 462 1441
690-3-60
152 149 145 187 161 140 121 832 NOTE 1
230-3-60
434 415 405 491 461 399 339 776 2420
200-3-50
456 430 418 538 466 420 365 764 2380
200-3-60
525 519 503 650 563 483 420
879 2737
FREQ Frequency
HP Horsepower
LRA Locked Rotor Amps
PH Phase
RLA Rated Load Amps
