It can be configured for intake from below
simply by inverting panels A and B.
During the operation, take the following
precautions to avoid damaging parts of the
unit:
remove the filter.
Before removing the rear panel (A) pull the
drain pipe out of its seat by pressing gently
on the sides.
When fitting the rear panel, take care not to
damage the insulation of the pipes with the
edges of the panels. On completion of the
operation, fit the filter.
AIR OUTLET CONFIGURATION
The Carrier 40DMC unit is predisposed for
either side or front air outlet.
Installation with front outlet
The standard factory configuration is with
front outlet and ducting with rectangular
conduits
GB-10
B
A
A
B
A
