Carrier 45 Series - Page 12

12
Table 10 — 45K Series Fan Powered Terminal Unit Performance
a,b,c
NOTE(S):
a. 45K maximum primary airflow (cfm) is set by the maximum induced airflow, which may vary as a function of downstream pressure. Maximum airflow shown is based on
the maximum induced airflow (fan airflow) or 1.00 in. wg differential pressure signal from inlet airflow sensor, whichever is less.
b. Minimum recommended primary airflow (cfm) is based on 0.03 in. wg differential pressure of the inlet airflow sensor, or 0 airflow. 0.03 in. wg is equal to 15% to 20% of
the nominal flow rating of the terminal. Less than 15% to 20% may result in greater than +5% control of box flow.
c. 45K maximum/minimum fan airflow is based on 0.10 in. wg / 0.60 in. wg downstream static pressure, respectively.
45K WITH PSC FAN MOTOR
UNIT SIZE INLET SIZE (in.)
FAN AIRFLOW
(cfm)
PRIMARY AIRFLOW
(cfm)
MOTOR
HP
MOTOR AMPS
MIN MAX MIN MAX 120V 208/240V 277V
2
6
50 530
52 or 0 515
1/10 1.4 0.8 0.6
8 92 or 0 530
3
6
200 1100
52 or 0 515
1/4 4.3 2.4 1.8
8 92 or 0 916
10 143 or 0 1100
12 360 or 0 1100
4
8
500 1300
92 or 0 916
1/4 4.3 2.4 1.810 143 or 0 1300
12 206 or 0 1300
5
10
800 1900
143 or 0 1432
1/2 8.3 4.4 3.512 206 or 0 1900
14 281 or 0 1900
6
10
1200 2600
143 or 0 1432
3/4 9.5 5.0 4.4
12 206 or 0 2062
14 281 or 0 2600
16 367 or 0 2600
7
10
1250 3000
143 or 0 1432
1 N/A 7.1 5.3
12 206 or 0 2062
14 281 or 0 2806
16 367 or 0 3000
45K WITH ECM FAN MOTOR
UNIT SIZE INLET SIZE (in.)
FAN AIRFLOW
(cfm)
PRIMARY AIRFLOW
(cfm)
MOTOR
HP
MOTOR AMPS
MIN MAX MIN MAX 120V 208/240V 277V
3
6
250 1030
52 or 0 515
1/2 7.7 5.0 4.1
8 92 or 0 916
10 143 or 0 1030
12 206 or 0 1030
6
10
500 2600
143 or 0 1432
1 12.8 10.5 6.9
12 206 or 0 2000
14 281 or 0 2000
16 367 or 0 2000
7
10
600 2500
143 or 0 1432
1 12.8 10.5 6.9
12 206 or 0 2062
14 281 or 0 2500
16 367 or 0 2500
