16
Table 4 – Air Delivery -- CFM (With Filter)*
COOLING
4
AND HEATING AIR DELIVERY - CFM (Bottom Return
5
With Filter)
(SW1-5 and SW2-2 set to OFF, except as indicated. See notes 1 and 2.)
Unit Size: 045V14-12 Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches: SW2-8 SW2-7 SW2-6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1190 1140 1100 1065 1020 985 905 800 665 525
Cooling
(SW2-8,7,6)
OFF OFF ON 620 560 520 455 410 355 305 255 See note 4
OFF ON OFF 795 755 705 670 615 585 530 490 440 405
OFF ON ON 1020 955 930 890 840 805 755 715 645 490
ON OFF OFF 1190 1140 1100 1065 1020 985 905 800 665 525
ON OFF ON 1455 1390 1325 1255 1175 1085 1000 880 755 575
ON ON OFF 1455 1390 1325 1255 1175 1085 1000 880 755 575
ON ON ON 1455 1390 1325 1255 1175 1085 1000 880 755 575
Maximum Clg Airflow
2
1455 1390 1325 1255 1175 1085 1000 880 755 575
CF Switches SW2-5 SW2-4 SW2-3
Low-Clg Default: OFF OFF OFF 620 560 520 455 410 355 305 255 See note 4
Low-Cooling
(SW2-5,4,3)
OFF OFF ON 620 560 520 455 410 355 305 255 See note 4
OFF ON OFF 795 755 705 670 615 585 530 490 440 405
OFF ON ON 1020 955 930 890 840 805 755 715 645 490
ON OFF OFF 1190 1140 1100 1065 1020 985 905 800 665 525
ON OFF ON 1455 1390 1325 1255 1175 1085 1000 880 755 575
ON ON OFF 1455 1390 1325 1255 1175 1085 1000 880 755 575
ON ON ON 1455 1390 1325 1255 1175 1085 1000 880 755 575
Cont. Fan Default: OFF OFF OFF 620 560 520 455 410 355 305 255 See note 4
Continuous Fan
(SW2-5,4,3)
OFF OFF ON 620 560 520 455 410 355 305 255 See note 4
OFF ON OFF 795 755 705 670 615 585 530 490 440 405
OFF ON ON 1020 955 930 890 840 805 755 715 645 490
ON OFF OFF 1020 955 930 890 840 805 755 715 645 490
ON OFF ON 1020 955 930 890 840 805 755 715 645 490
ON ON OFF 1020 955 930 890 840 805 755 715 645 490
ON ON ON 1020 955 930 890 840 805 755 715 645 490
Heating
(SW1)
High Heat Airflow
3
915 860 825 790 735 700 650 610 550 450
Low Heat Airflow
3
780 730 685 635 585 545 495 450 400 370
Unit Size: 070V14-12 Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches: SW2-8 SW2-7 SW2-6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1155 1125 1095 1065 1035 1005 975 950 915 875
Cooling
(SW2-8,7,6)
OFF OFF ON 605 555 500 440 375 320 265 See note 4
OFF ON OFF 775 735 690 650 600 550 500 450 405 365
OFF ON ON 980 950 915 880 845 810 775 735 695 655
ON OFF OFF 1155 1125 1095 1065 1035 1005 975 950 915 875
ON OFF ON 1370 1340 1310 1285 1260 1235 1210 1140 1025 880
ON ON OFF 1505 1480 1455 1420 1380 1335 1250 1155 1045 900
ON ON ON 1505 1480 1455 1420 1380 1335 1250 1155 1045 900
Maximum Clg Airflow
2
1505 1480 1455 1420 1380 1335 1250 1155 1045 900
CF Switches SW2-5 SW2-4 SW2-3
Low-Clg Default: OFF OFF OFF 605 555 500 440 375 320 265 See note 4
Low-Cooling
(SW2-5,4,3)
OFF OFF ON 605 555 500 440 375 320 265 See note 4
OFF ON OFF 775 735 690 650 600 550 500 450 405 365
OFF ON ON 980 950 915 880 845 810 775 735 695 655
ON OFF OFF 1155 1125 1095 1065 1035 1005 975 950 915 875
ON OFF ON 1370 1340 1310 1285 1260 1235 1210 1140 1025 880
ON ON OFF 1505 1480 1455 1420 1380 1335 1250 1155 1045 900
ON ON ON 1505 1480 1455 1420 1380 1335 1250 1155 1045 900
Cont. Fan Default: OFF OFF OFF 605 555 500 440 375 320 265 See note 4
Continuous Fan
(SW2-5,4,3)
OFF OFF ON 605 555 500 440 375 320 265 See note 4
OFF ON OFF 775 735 690 650 600 550 500 450 405 365
OFF ON ON 980 950 915 880 845 810 775 735 695 655
ON OFF OFF 1155 1125 1095 1065 1035 1005 975 950 915 875
ON OFF ON 1370 1340 1310 1285 1260 1235 1210 1140 1025 880
ON ON OFF 1370 1340 1310 1285 1260 1235 1210 1140 1025 880
ON ON ON 1370 1340 1310 1285 1260 1235 1210 1140 1025 880
Heating
(SW1)
High Heat Airflow
3
1190 1160 1130 1100 1070 1045 1015 985 955 900
Low Heat Airflow
3
725 680 635 585 530 475 425 375 330 285
