Carrier 58TP0A - Page 17

17
Table 4 -- Air Delivery -- CFM (With Filter)* (CONTINUED)
COOLING
4
AND HEATING AIR DELIVERY - CFM (Bottom Return
5
With Filter)
(SW1-5 and SW2-2 set to OFF, except as indicated. See notes 1 and 2.)
Unit Size: 070V17-16 Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches: SW2-8 SW2-7 SW2-6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1600 1570 1535 1500 1465 1430 1400 1365 1335 1300
Cooling
(SW2-8,7,6)
OFF OFF ON 590 520 440 365 300 235 See note 4
OFF ON OFF 790 730 670 610 550 485 430 380 330 275
OFF ON ON 1025 980 930 880 835 785 735 690 635 590
ON OFF OFF 1230 1190 1150 1105 1065 1025 980 940 900 860
ON OFF ON 1390 1355 1315 1280 1240 1200 1165 1125 1090 1055
ON ON OFF 1600 1570 1535 1500 1465 1430 1400 1365 1335 1300
ON ON ON 1855 1830 1800 1770 1740 1695 1645 1600 1520 1415
Maximum Clg Airflow
2
1855 1830 1800 1770 1740 1695 1645 1600 1520 1415
CF Switches SW2-5 SW2-4 SW2-3
Low-Clg Default: OFF OFF OFF 590 520 440 365 300 235 See note 4
Low-Cooling
(SW2-5,4,3)
OFF OFF ON 590 520 440 365 300 235 See note 4
OFF ON OFF 790 730 670 610 550 485 430 380 330 275
OFF ON ON 1025 980 930 880 835 785 735 690 635 590
ON OFF OFF 1230 1190 1150 1105 1065 1025 980 940 900 860
ON OFF ON 1390 1355 1315 1280 1240 1200 1165 1125 1090 1055
ON ON OFF 1600 1570 1535 1500 1465 1430 1400 1365 1335 1300
ON ON ON 1855 1830 1800 1770 1740 1695 1645 1600 1520 1415
Cont. Fan Default: OFF OFF OFF 590 520 440 365 300 235 See note 4
Continuous Fan
(SW2-5,4,3)
OFF OFF ON 590 520 440 365 300 235 See note 4
OFF ON OFF 685 625 565 505 445 385 325 265 See note 4
OFF ON ON 790 730 670 610 550 485 430 380 330 275
ON OFF OFF 790 730 670 610 550 485 430 380 330 275
ON OFF ON 790 730 670 610 550 485 430 380 330 275
ON ON OFF 790 730 670 610 550 485 430 380 330 275
ON ON ON 790 730 670 610 550 485 430 380 330 275
Heating
(SW1)
High Heat Airflow
3
1410 1375 1340 1300 1260 1225 1190 1155 1120 1085
Low Heat Airflow
3
1235 1195 1155 1110 1070 1025 985 945 905 865
Unit Size: 090V17-16 Clg/CF Switch settings External Static Pressure (ESP)
Clg Switches: SW2-8 SW2-7 SW2-6 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
Clg Default: OFF OFF OFF 1560 1520 1485 1450 1415 1380 1340 1300 1260 1115
Cooling
(SW2-8,7,6)
OFF OFF ON 680 605 495 415 345 275 See note 4
OFF ON OFF 835 770 700 600 535 465 410 350 285 240
OFF ON ON 1035 980 930 870 795 720 665 605 555 505
ON OFF OFF 1210 1165 1125 1080 1030 975 905 845 790 740
ON OFF ON 1375 1335 1300 1260 1220 1175 1125 1075 1010 955
ON ON OFF 1560 1520 1485 1450 1415 1380 1340 1300 1260 1115
ON ON ON 1640 1605 1570 1540 1505 1470 1435 1390 1325 1110
Maximum Clg Airflow
2
1640 1605 1570 1540 1505 1470 1435 1390 1325 1110
CF Switches SW2-5 SW2-4 SW2-3
Low-Clg Default: OFF OFF OFF 680 605 495 415 345 275 See note 4
Low-Cooling
(SW2-5,4,3)
OFF OFF ON 680 605 495 415 345 275 See note 4
OFF ON OFF 835 770 700 600 535 465 410 350 285 240
OFF ON ON 1035 980 930 870 795 720 665 605 555 505
ON OFF OFF 1210 1165 1125 1080 1030 975 905 845 790 740
ON OFF ON 1375 1335 1300 1260 1220 1175 1125 1075 1010 955
ON ON OFF 1560 1520 1485 1450 1415 1380 1340 1300 1260 1115
ON ON ON 1640 1605 1570 1540 1505 1470 1435 1390 1325 1110
Cont. Fan Default: OFF OFF OFF 680 605 495 415 345 275 See note 4
Continuous Fan
(SW2-5,4,3)
OFF OFF ON 680 605 495 415 345 275 See note 4
OFF ON OFF 835 770 700 600 535 465 410 350 285 240
OFF ON ON 1035 980 930 870 795 720 665 605 555 505
ON OFF OFF 1210 1165 1125 1080 1030 975 905 845 790 740
ON OFF ON 1375 1335 1300 1260 1220 1175 1125 1075 1010 955
ON ON OFF 1560 1520 1485 1450 1415 1380 1340 1300 1260 1115
ON ON ON 1560 1520 1485 1450 1415 1380 1340 1300 1260 1115
Heating
(SW1)
High Heat Airflow
3
1400 1360 1325 1285 1245 1200 1155 1110 1045 995
Low Heat Airflow
3
1035 980 930 870 795 720 665 605 555 505
