9 REFRIGERATION UNIT - AREA LOCATOR
Item Section Number in
Current Document
Section Number in
Manual T-318PL. Refer to:
Area Description
1 Section 10 Section 2.7 Control Box
2 Section 11 Section 2.12 Compressor Tubing
3 Section 13 Section 2.13 Receiver
4 Section 14 Section 2.20 Evaporator Coil
5 Section 15 Section 2.22 Back Panel Assembly
6 Section 16 Section 2.33 Labels and Decals
7 Section 17 — Remote Evaporator - Frame
8 Section 18 — Remote Evaporator - Refrigeration
9 Section 19 — Remote Evaporator - Electrical Kit
10 Section 21 — Remote Evaporator - Wire Harness
11 Section 23 — Remote Evaporator - Heater Kit
12 Section 25 — Remote Evaporator - Installation Components
2
3
1
6
4, 5
7
12
8, 9, 10, 11, 12
