Carrier BT30RF- EXPR - Page 101

EVAPORATOR COIL ASSEMBLY
SECTION 'B-B'
45
REMOTE MODELS,
STRAINER INSERTED
PRIOR TO BRAZING
5
4
3
STRAINER, INLET TXV
RETAINER, HEATER
HEATER, DEFROST
4
5
DESCRIPTION
EXPANSION VALVE
EVAPORATOR COIL
SEQ
2
1
1
2
'A'
'B'
'A'
'B'
SECTION 'A-A'
INCUBATOR
5
ATTACH RETAINER IN
THIS POSITION AT ALL
LOCATIONS EXCEPT ENDS
5
3
THIS POSITION AT
ATTACH RETAINER IN
ENDS OF COIL
EXPANSION VALVE BULB
EXP. VALVE MTG. STRAP
1/16
EVAPORATOR COIL ILLUSTRATION 103
