Medium Temperature, Bottom Mount, Glass
Pull Door Refrigerators Specifications
BOTTOM MOUNT REFRIGERATOR SPECIFICATIONS 11
Specification 1-Door 2-Door 3-Door
Compressor Mount Bottom Bottom Bottom
Temperature Range 32° to 55° (0° to 13°C) 32° to 55° (0° to 13°C) 32° to 55° (0° to 13°C)
Number of Doors 1 2 3
Door Construction Double Pane Double Pane Double Pane
Hinge Type Torsion Bar Torsion Bar Torsion Bar
Insulation - CFC-Free Foam-in-Place Urethane Foam-in-Place Urethane Foam-in-Place Urethane
Wall Thickness 2 3/8" 2 3/8" 2 3/8"
Capacity - Gross 27.3 ft.
3
49.1 ft.
3
76.2 ft.
3
Shipping Weight (Approx.) 488 lbs. 640 lbs. 724 lbs.
Compressor BTUH/-10°F Evap. 2400 5400 5400
Condenser Type Fin & Tube Forced Air Fin & Tube Forced Air Fin & Tube Forced Air
Evaporator Type Fin & Tube Forced Air Fin & Tube Forced Air Fin & Tube Forced Air
Refrigerant Type R-404A R-404A R-404A
Refrigerant Control Expansion Valve Expansion Valve Expansion Valve
Amp Rating 9.5 12.1 14.5
Electrical Specs. (V / Hz / Ph) 115 / 60 / 1 115 / 60 / 1 115 / 60 / 1
NSF NSF7 NSF7 NSF7
UL & CSA Listed Yes Yes Yes
Interior Finish Baked Enamel, Coved Corners Baked Enamel, Coved Corners Baked Enamel, Coved Corners
Exterior Finish Baked Enamel Baked Enamel Baked Enamel
Lighting
2 Insul. 1500 Milliamp Fluor. Lamps 3 Insul. 1500 Milliamp Fluor. Lamps 4 Insul. 1500 Milliamp Fluor. Lamps
Electrical Information 15 Amp Service Cord 20 Amp Service Cord 20 Amp Service Cord
w/NEMA 5-15P Plug w/NEMA 5-20P Plug w/NEMA 5-20P Plug
