SHELVING / DRAWER
Installation & Adjustment
To install shelves or drawers in a level position, insert
the cantilever plate tabs into the rectangular holes in
the desired position on the shelf standard. Lower the
rear of the shelf so that the slots in the plate are com-
pletely down over the bottom of the holes.
NOTE: Supporting the front of the shelf with one hand
while pushing down on the rear of the shelf will help
ease installation.
To slope shelves, insert the cantilever plate tabs into
the rectangular holes in the desired position on the
shelf standard. Lift up on the rear of the shelf so that
the top tab is locked behind the top of the rectangular
hole. Hold the rear of the shelf up while lowering the
front of the shelf until the bottom tab is inserted in the
appropriate hole in the shelf standard.
MAINTENANCE & REPAIR 61
