ELECTRICAL & REFRIGERATION SPECS. BT30RF-FMS
Medium Temp., Solid, 1-Door Refrigerators
Compressor Model Number Americold HP110-1-3083
Compressor BTUH / -10°F Evaporator 1013
Recommended Operating Temp. Range (F/C) 35°F to 50°F (2°C to 10°C)
Cabinet Volts 115
Expansion Device Capillary .031 x 7"
Charge Refrig. Type / Oz. / Grams R404A / 13 / 368.5
SYSTEM COMPONENTS – R-404A
AMBIENT 70°F / 21.1°C 80°F / 27°C 90°F / 32.5°C
Cavity Temp. (F/C) 37 / 2.7 42 / 5.5 44 / 6.6
Suction Pressure (PSIG / Kpa) 4.8 / 33 8.1 / 56 11.9 / 82
Discharge Pressure (PSIG / Kpa) 180 / 1241 227 / 1565 262 / 1806
Compressor Amps 1.2 1.2 1.3
Total Refrigeration Amps 1.2 1.3 1.4
Freezer Temp. -3 / -19.5 -2 / -18.9 8 / -13
SYSTEM PERFORMANCE
ELECTRICAL / REFRIGERATION SPECIFICATIONS 65
