Carrier Connect 33CONNECTSTAT43 User Manual

33CONNECTSTAT43 ©2022 Carrier.
Installation Guide All rights reserved.
1
The Carrier® Connect™ Wi-Fi Thermostat (Part #33CONNECTSTAT43) is a thermistor-based wireless thermostat
that can sense a 10K Type II OAT or a remote space or return air sensor and can control up to 4 heating and 3
cooling stages.
The Carrier® Connect™ Wi-Fi Thermostat package includes:
• Thermostat
• Mounting Hardware - two screws with drywall anchors and one security screw
• Quick Start Guide - Catalog No. 11-808-729-01
Some of the features:
• Supporting standard air conditioning and heat pump rooftop and split units
• 7-day scheduling with up to 4 periods per day
• Holiday scheduling
• Full-color touchscreen that’s easy to navigate
• Remote programming and monitoring using secure Apple® or Android® mobile app or Web portal
• Text and email service alerts
• Automatic software updates via Wi-Fi
Specifications
Power requirements
24 Vac +/- 10% @ 3VA
Network Requirements
Wi-Fi connectivity supports Wi-Fi: 802.11 a/b/g/n standards on 2.4 GHz networks
Environmental
operating range
32° to 104°F (0° to 40°C), 10 to 95% relative humidity, non condensing
Mounting
Standard 4 x 2 in. electrical box using the 6-32 x 1/2 in. mounting screws provided
Overall dimensions
Width:
Height:
Depth:
5.13 in. (13 cm)
3.23 in. (8.2 cm)
0.94 in. (2.4 cm)
BACnet Support
Conforms to the BACnet Application Specific Controller (B-ASC) Device Profile as defined
in ANSI/ ASHRAE Standard 135-2012 (BACnet) Annex L, Protocol Revision 14
Listed by
FCC Part 15, Subpart J compliant
What is the Carrier Connect™ Wi-Fi Thermostat?

Carrier Connect 33CONNECTSTAT43 Specifications

General

Brand	Carrier
Model	Connect 33CONNECTSTAT43
Category	Thermostat
Language	English
