Table 8 — 30GX080-350 Condenser Fan Staging (PSIO-1 Controlled)
LEGEND
*Fan Relay number displayed when using to test fans.
†Proper rotation of these fans to be checked when compressor(s) is running. See Fig. 5 for
condenser fan locations when viewing from the control box end.
NOTE: For 30GX151, 161-350 units, fan relays 1 and 2 energize Circuit A fans. Fan relays
3 and 4 energize Circuit B fans.
30GX UNIT SIZE FAN TYPE FAN CONTACTOR FANS CONTROLLED FAN RELAY NO.*
080-105
Standard
FC-1 1, 2 5
FC-2 3, 4 1
High Static
FC-1, 1A 1, 2 5
FC-2, 2A 3, 4 1
106-125
Standard
FC-1 1, 2 5
FC-2 3, 4 1
FC-3 5, 6 2
High Static
FC-1, 1A 1, 2 5
FC-2, 2A 3, 4 1
FC-3, 3A 5, 6 2
136, 150, 160
Standard
FC-1 1, 2 5
FC-2 3, 4 1
FC-3 5, 6 2
FC-4 7, 8 2
High Static
FC-1, 1A 1, 2 5
FC-2, 2A 3, 4 1
FC-3, 3A 5, 6 2
FC-4, 4A 7, 8 2
151, 161, 175, 205, 225
Standard
FC-1 1, 2 Comp. B1 contactor†
FC-2 3, 4 3
FC-3 5, 6 2
FC-4 7, 8 Comp. A1/A2 contactor†
FC-5 9, 10 1
High Static
FC-1, 1A 1, 2 Comp. B1 contactor†
FC-2, 2A 3, 4 3
FC-3, 3A 5, 6 2
FC-4, 4A 7, 8 Comp. A1/A2 contactor†
FC-5, 5A 9, 10 1
176
Standard
FC-1 1, 2 Comp. B1 contactor†
FC-2 3, 4 3
FC-3 5, 6 4
FC-4 7, 8 Comp. A1 contactor†
FC-5 9, 10 1
FC-6 11, 12 2
High Static
FC-1, 1A 1, 2 Comp. B1 contactor†
FC-2, 2A 3, 4 3
FC-3, 3A 5, 6 4
FC-4, 4A 7, 8 Comp. A1 contactor†
FC-5, 5A 9, 10 1
FC-6, 6A 11, 12 2
206, 226, 250
Standard
FC-1 1, 2 Comp. B1 contactor†
FC-2 3, 4 3
FC-3 5, 6 1
FC-4 7, 8 Comp. A1/A2 contactor†
FC-5 9, 10 2
FC-6 11, 12 2
High Static
FC-1, 1A 1, 2 Comp. B1 contactor†
FC-2, 2A 3, 4 3
FC-3, 3A 5, 6 1
FC-4, 4A 7, 8 Comp. A1/A2 contactor†
FC-5, 5A 9, 10 2
FC-6, 6A 11, 12 2
251, 265
Standard
FC-1 2, 4 1
FC-2 6, 8 2
FC-3 1 Comp. B1 contactor†
FC-4 3 3
FC-5 5, 7 4
FC-6 9, 10 Comp. A1/A2 contactor†
FC-7 11, 12 2
FC-8 13, 14 2
High Static
FC-1, 1A 2, 4 1
FC-2, 2A 6, 8 2
FC-3 1 Comp. B1 contactor†
FC-4 3 3
FC-5, 5A 5, 7 4
FC-6, 6A 9, 10 Comp. A1/A2 contactor†
FC-7, 7A 11, 12 2
FC-8, 8A 13, 14 2
281-350
Standard
FC-1 1, 2 Comp. B1/B2 contactor†
FC-2 3, 4 3
FC-3 5, 6 4
FC-4 7, 8 4
FC-5 9, 10 1
FC-6 11, 12 Comp. A1/A2 contactor†
FC-7 13, 14 2
FC-8 15, 16 2
High Static
FC-1, 1A 1, 2 Comp. B1/B2 contactor†
FC-2, 2A 3, 4 3
FC-3, 3A 5, 6 4
FC-4, 4A 7, 8 4
FC-5, 5A 9, 10 1
FC-6, 6A 11, 12 Comp. A1/A2 contactor†
FC-7, 7A 13, 14 2
FC-8, 8A 15, 16 2
Comp. —
Compressor
FC —
Fan Contactor
