APPENDIX A (cont)
Compressor Protection Module Configuration Header Punch-Outs and Must Trip Amps
UNIT
MODEL
NUMBER
PUNCH OUTS
FOR
COMP A1
PUNCH OUTS
FOR
COMP A2
PUNCH OUTS
FOR
COMP B1
COMP A1
MUST TRIP AMPS
SETTING
COMP A2
MUST TRIP AMPS
SETTING
COMP B1
MUST TRIP AMPS
SETTING
30HXA116---1 1, 2, 4 — 1, 2, 3, 6, 7, 8 144 — 98
30HXA116---2 1, 3, 5, 7, 8 — 1, 2, 5, 6, 7 218 — 148
30HXA116---3 1, 4, 5, 7, 8 — 1, 2, 7, 8 250 — 170
30HXA116---5 2, 4 — 1, 4, 8 400 — 270
30HXA116---6 1, 3, 4, 5, 6, 7 — 1, 2, 4, 5, 7, 8 180 — 122
30HXA116---8 2, 4, 5, 6 — 1, 4, 5 376 — 256
30HXA116---9 1, 3, 6, 7 — 1, 2, 5, 7 228 — 156
30HXA126---1 1, 2, 4 — 1, 2, 4, 5, 6 144 — 120
30HXA126---2 1, 3, 5, 7, 8 — 1, 3, 4, 5, 6, 7 218 — 180
30HXA126---3 1, 4, 5, 7, 8 — 1, 3, 4, 8 250 — 206
30HXA126---5 2, 4 — 2, 3, 4, 6 400 — 328
30HXA126---6 1, 3, 4, 5, 6, 7 — 1, 2, 5, 6, 7 180 — 148
30HXA126---8 2, 4, 5, 6 — 2, 3, 4, 5, 6, 8 376 — 310
30HXA126---9 1, 3, 6, 7 — 1, 3, 4, 5, 7 228 — 188
30HXA136---1 1, 2 — 1, 2, 4, 5, 6 176 — 120
30HXA136---2 1, 4, 7, 8 — 1, 3, 4, 5, 6, 7 266 — 180
30HXA136---3 2, 3, 4, 5, 6, 7, 8 — 1, 3, 4, 8 306 — 206
30HXA136---5 3, 6, 8 — 2, 3, 4, 6 486 — 328
30HXA136---6 1, 3, 5, 7 — 1, 2, 5, 6, 7 220 — 148
30HXA136---8 3, 4, 8 — 2, 3, 4, 5, 6, 8 462 — 310
30HXA136---9 1, 5, 6 — 1, 3, 4, 5, 7 280 — 188
30HXA146---1 1, 2 — 1, 2, 4 176 — 144
30HXA146---2 1, 4, 7, 8 — 1, 3, 5, 7, 8 266 — 218
30HXA146---3 2, 3, 4, 5, 6, 7, 8 — 1, 4, 5, 7, 8 306 — 250
30HXA146---5 3, 6, 8 — 2, 4 486 — 400
30HXA146---6 1, 3, 5, 7 — 1, 3, 4, 5, 6, 7 220 — 180
30HXA146---8 3, 4, 8 — 2, 4, 5, 6 462 — 376
30HXA146---9 1, 5, 6 — 1, 3, 6, 7 280 — 228
30HXA161---1 1, 3, 4, 6, 8 — 1, 2, 4, 6, 8 198 — 134
30HXA161---2 1, 7 — 1, 3, 4, 7, 8 300 — 202
30HXA161---3 2, 3, 5, 6 — 1, 3, 6, 7 344 — 228
30HXA161---5 6, 7, 8 — 2, 3 546 — 368
30HXA161---6 1, 4, 5, 6 — 1, 2, 6 248 — 168
30HXA161---8 4, 6 — 2, 3, 5, 6 520 — 344
30HXA161---9 2, 3, 4, 5, 7, 8 — 1, 3, 4 314 — 208
30HXA171---1 1, 2, 6, 7, 8 — 1, 3, 4, 6, 8 162 — 198
30HXA171---2 1, 4, 5, 6, 8 — 1,7 246 — 300
30HXA171---3 1, 5, 6, 8 — 2, 3, 5, 6 278 — 344
30HXA171---5 3, 4, 5 — 6, 7, 8 448 — 546
30HXA171---6 1, 3, 4, 7 — 1, 4, 5, 6 204 — 248
30HXA171---8 2, 6, 7, 8 — 4, 6 418 — 520
30HXA171---9 1, 4, 5, 8 — 2, 3, 4, 5, 7, 8 254 — 314
30HXA186---1 1, 3, 4, 6, 8 — 1, 3, 4, 6, 8 198 — 198
30HXA186---2 1, 7 — 1, 7 300 — 300
30HXA186---3 2, 3, 5, 6 — 2, 3, 5, 6 344 — 344
30HXA186---5 6, 7, 8 — 6, 7, 8 546 — 546
30HXA186---6 1, 4, 5, 6 — 1, 4, 5, 6 248 — 248
30HXA186---8 4, 6 — 4, 6 520 — 520
30HXA186---9 2, 3, 4, 5, 7, 8 — 2, 3, 4, 5, 7, 8 314 — 314
30HXA206---1 1, 2, 6, 7, 8 1, 2, 3, 5, 7 1, 3, 4, 6, 8 162 92 198
30HXA206---2 1, 4, 5, 6, 8 1, 2, 4, 7 1, 7 246 138 300
30HXA206---3 1, 5, 6, 8 1, 2, 5, 8 2, 3, 5, 6 278 158 344
30HXA206---5 3, 4, 5 1, 4, 5, 8 6, 7, 8 448 254 546
30HXA206---6 1, 3, 4, 7 1, 2, 4, 5, 6, 7, 8 1, 4, 5, 6 204 116 248
30HXA206---8 2, 6, 7, 8 1, 3, 8 4, 6 418 238 520
30HXA206---9 1, 4, 5, 8 1, 2, 4 2, 3, 4, 5, 7, 8 254 144 314
1
8
