Carrier Ecologic Series 3 User Manual

77
APPENDIX A (cont)
Compressor Protection Module Configuration Header Punch-Outs and Must Trip Amps
UNIT
MODEL
NUMBER
PUNCH OUTS
FOR
COMP A1
PUNCH OUTS
FOR
COMP A2
PUNCH OUTS
FOR
COMP B1
PUNCH OUTS
FOR
COMP B2
COMP A1
MUST TRIP AMPS
SETTING
COMP A2
MUST TRIP AMPS
SETTING
COMP B1
MUST TRIP AMPS
SETTING
COMP B2
MUST TRIP AMPS
SETTING
30GX-205---8 2, 6, 7, 8 1, 3, 8 4, 6 — 418 238 520 —
30GX-205---9 1, 4, 5, 8 1, 2, 4 2, 3, 4, 5, 7, 8 — 254 144 314 —
30GX-206---1 1, 3, 4, 6, 8 1, 2, 3, 5, 7 1, 2, 6, 7, 8 — 198 92 162 —
30GX-206---2 1, 7 1, 2, 4, 7 1, 4, 5, 6, 8 — 300 140 246 —
30GX-206---5 6, 7, 8 1, 4, 5, 8 3, 4, 5 — 546 254 448 —
30GX-206---6 1, 4, 5, 6 1, 2, 4, 5, 6, 7, 8 1, 3, 4, 7 — 248 114 204 —
30GX-225---8 4, 6 1, 5 4, 6 — 520 288 520 —
30GX-225---9 2, 3, 4, 5, 7, 8 1, 2, 8 2, 3, 4, 5, 7, 8 — 314 168 314 —
30GX-226---1 1, 3, 4, 6, 8 1, 2, 3, 8 1, 3, 4, 6, 8 — 198 110 198 —
30GX-226---2 1, 7 1, 2, 6 1, 7 — 300 168 300 —
30GX-226---5 6, 7, 8 2, 3, 4, 5, 6, 7, 8 6, 7, 8 — 546 306 546 —
30GX-226---6 1, 4, 5, 6 1, 2, 4, 7, 8 1, 4, 5, 6 — 248 138 248 —
30GX-226---8 4, 6 1, 5 4, 6 — 520 388 520 —
30GX-226---9 2, 3, 4, 5, 7, 8 1, 2, 8 2, 3, 4, 5, 7, 8 — 314 174 314 —
30GX-250---8 4, 6 2, 6, 7, 8 4, 6 — 520 418 520 —
30GX-250---9 2, 3, 4, 5, 7, 8 1, 4, 5, 6 2, 3, 4, 5, 7, 8 — 314 254 314 —
30GX-251---1 1, 3, 4, 6, 8 1, 3, 4, 6, 8 1, 2, 6, 7, 8 — 198 198 162 —
30GX-251---2 1, 7 1, 7 1, 4, 5, 6, 8 — 300 300 246 —
30GX-251---5 6, 7, 8 6, 7, 8 3, 4, 5 — 546 546 448 —
30GX-251---6 1, 4, 5, 6 1, 4, 5, 6 1, 3, 4, 7 — 248 248 204 —
30GX-265---1 1, 3, 4, 6, 8 1, 3, 4, 6, 8 1, 3, 4, 6, 8 — 198 198 198 —
30GX-265---2 1, 7 1, 7 1, 7 — 300 300 300 —
30GX-265---5 6, 7, 8 6, 7, 8 6, 7, 8 — 546 546 546 —
30GX-265---6 1, 4, 5, 6 1, 4, 5, 6 1, 4, 5, 6 — 248 248 248 —
30GX-265---8 4, 6 4, 6 4, 6 — 520 520 520 —
30GX-265---9 2, 3, 4, 5, 7, 8 2, 3, 4, 5, 7, 8 2, 3, 4, 5, 7, 8 — 314 314 314 —
30GX-281---1 1, 3, 4, 6, 8 1, 2, 3, 8 1, 3, 4, 6, 8 1, 2, 3, 8 198 110 198 110
30GX-281---2 1, 7 1, 2, 6 1, 7 1, 2, 6 300 168 300 168
30GX-281---6 1, 4, 5, 6 1, 2, 4, 7, 8 1, 4, 5, 6 1, 2, 4, 7, 8 248 138 248 138
30GX-281---9 2, 3, 4, 5, 7, 8 1, 2, 8 2, 3, 4, 5, 7, 8 1, 2, 8 314 174 314 174
30GX-301---1 1, 3, 4, 6, 8 1, 2, 4, 6, 8 1, 3, 4, 6, 8 1, 2, 4, 6, 8 198 134 198 134
30GX-301---2 1, 7 1, 3, 4, 7, 8 1, 7 1, 3, 4, 7, 8 300 202 300 202
30GX-301---6 1, 4, 5, 6 1, 2, 6 1, 4, 5, 6 1, 2, 6 248 168 248 168
30GX-301---9 2, 3, 4, 5, 7, 8 1, 3, 4 2, 3, 4, 5, 7, 8 1, 3, 4 314 208 314 208
30GX-325---1 1, 3, 4, 6, 8 1, 2, 6, 7, 8 1, 3, 4, 6, 8 1, 2, 6, 7, 8 198 162 198 162
30GX-325---2 1, 7 1, 4, 5, 6, 8 1, 7 1, 4, 5, 6, 8 300 246 300 246
30GX-325---6 1, 4, 5, 6 1, 3, 4, 7 1, 4, 5, 6 1, 3, 4, 7 248 204 248 204
30GX-325---9 2, 3, 4, 5, 7, 8 1, 4, 5, 8 2, 3, 4, 5, 7, 8 1, 4, 5, 8 314 254 314 254
30GX-350---1 1, 3, 4, 6, 8 1, 3, 4, 6, 8 1, 3, 4, 6, 8 1, 3, 4, 6, 8 198 198 198 198
30GX-350---2 1, 7 1, 7 1, 7 1, 7 300 300 300 300
30GX-350---6 1, 4, 5, 6 1, 4, 5, 6 1, 4, 5, 6 1, 4, 5, 6 248 248 248 248
30GX-350---9 2, 3, 4, 5, 7, 8 2, 3, 4, 5, 7, 8 2, 3, 4, 5, 7, 8 2, 3, 4, 5, 7, 8 314 314 314 314
30HXA076---1 1, 2, 3, 5, 6, 7, 8 — 1, 2, 5, 6, 7, 8 — 82 — 82 —
30HXA076---2 1, 2, 4, 5, 7 — 1, 2, 4, 5, 7 — 124 — 124 —
30HXA076---3 1, 2, 4, 7 — 1, 2, 4, 7 — 140 — 140 —
30HXA076---5 1, 3, 6, 7, 8 — 1, 3, 6, 7, 8 — 226 — 226 —
30HXA076---6 1, 2, 3, 6, 8 — 1, 2, 3, 6, 8 — 102 — 102 —
30HXA076---8 1, 3, 5, 6, 7 — 1, 3, 5, 6, 7 — 212 — 212 —
30HXA076---9 1, 2, 4, 5 — 1, 2, 4, 5 — 128 — 128 —
30HXA086---1 1, 2, 3, 6, 7, 8 — 1, 2, 3, 5, 6, 7, 8 — 98 — 82 —
30HXA086---2 1, 2, 5, 6, 7 — 1, 2, 4, 5, 7 — 148 — 124 —
30HXA086---3 1, 2, 7, 8 — 1, 2, 4, 7 — 170 — 140 —
30HXA086---5 1, 4, 8 — 1, 3, 6, 7, 8 — 270 — 226 —
30HXA086---6 1, 2, 4, 5, 7, 8 — 1, 2, 3, 6, 8 — 122 — 102 —
30HXA086---8 1, 4, 5 — 1, 3, 5, 6, 7 — 256 — 212 —
30HXA086---9 1, 2, 5, 7 — 1, 2, 4, 5 — 156 — 128 —
30HXA096---1 1, 2, 4, 5, 6 — 1, 2, 3, 5, 6, 7, 8 — 120 — 82 —
30HXA096---2 1, 3, 4, 5, 6, 7 — 1, 2, 4, 5, 7 — 180 — 124 —
30HXA096---3 1, 3, 4, 8 — 1, 2, 4, 7 — 206 — 140 —
30HXA096---5 2, 3, 4, 6 — 1, 3, 6, 7, 8 — 328 — 226 —
30HXA096---6 1, 2, 5, 6, 7 — 1, 2, 3, 6, 8 — 148 — 102 —
30HXA096---8 2, 3, 4, 5, 6, 8 — 1, 3, 5, 6, 7 — 310 — 212 —
30HXA096---9 1, 3, 4, 5, 7 — 1, 2, 4, 5 — 188 — 128 —
30HXA106---1 1, 2, 4 — 1, 2, 3, 5, 6, 7, 8 — 144 — 82 —
30HXA106---2 1, 3, 5, 7, 8 — 1, 2, 4, 5, 7 — 218 — 124 —
30HXA106---3 1, 4, 5, 7, 8 — 1, 2, 4, 7 — 250 — 140 —
30HXA106---5 2, 4 — 1, 3, 6, 7, 8 — 400 — 226 —
30HXA106---6 1, 3, 4, 5, 6, 7 — 1, 2, 3, 6, 8 — 180 — 102 —
30HXA106---8 2, 4, 5, 6 — 1, 3, 5, 6, 7 — 376 — 212 —
30HXA106---9 1, 3, 6, 7 — 1, 2, 4, 5 — 228 — 128 —
