Carrier Ecologic Series 3 - Appendix A

79
APPENDIX A (cont)
Compressor Protection Module Configuration Header Punch-Outs and Must Trip Amps
UNIT
MODEL
NUMBER
PUNCH OUTS
FOR
COMP A1
PUNCH OUTS
FOR
COMP A2
PUNCH OUTS
FOR
COMP B1
COMP A1
MUST TRIP AMPS
SETTING
COMP A2
MUST TRIP AMPS
SETTING
COMP B1
MUST TRIP AMPS
SETTING
30HXA246---1 1, 3, 4, 6, 8 1, 2, 4, 6, 8 1, 3, 4, 6, 8 198 134 198
30HXA246---2 1, 7 1, 3, 4, 7, 8 1, 7 300 202 300
30HXA246---3 2, 3, 5, 6 1, 3, 6, 7 2, 3, 5, 6 344 228 344
30HXA246---5 6, 7, 8 2, 3 6, 7, 8 546 368 546
30HXA246---6 1, 4, 5, 6 1, 2, 6 1, 4, 5, 6 248 168 248
30HXA246---8 4, 6 2, 3, 5 ,6 4, 6 520 344 520
30HXA246---9 2, 3, 4, 5, 7, 8 1, 3, 4 2, 3, 4, 5, 7, 8 314 208 314
30HXA261---1 1, 3, 4, 6, 8 1, 2, 6, 7, 8 1, 3, 4, 6, 8 198 162 198
30HXA261---2 1, 7 1, 4, 5, 6, 8 1, 7 300 246 300
30HXA261---3 2, 3, 5, 6 1, 5, 6, 8 2, 3, 5, 6 344 278 344
30HXA261---5 6, 7, 8 3, 4, 5 6, 7, 8 546 448 546
30HXA261---6 1, 4, 5, 6 1, 3, 4, 7 1, 4, 5, 6 248 204 248
30HXA261---8 4, 6 2, 6, 7, 8 4, 6 520 418 520
30HXA261---9 2, 3, 4, 5, 7, 8 1, 4, 5, 8 2, 3, 4, 5, 7, 8 314 254 314
30HXA271---1 1, 3, 4, 6, 8 1, 3, 4, 6, 8 1, 3, 4, 6, 8 198 198 198
30HXA271---2 1, 7 1, 7 1, 7 300 300 300
30HXA271---3 2, 3, 5, 6 2, 3, 5, 6 2, 3, 5, 6 344 344 344
30HXA271---5 6, 7, 8 6, 7, 8 6, 7, 8 546 546 546
30HXA271---6 1, 4, 5, 6 1, 4, 5, 6 1, 4, 5, 6 248 248 248
30HXA271---8 4, 6 4, 6 4, 6 520 520 520
30HXA271---9 2, 3, 4, 5, 7, 8 2, 3, 4, 5, 7, 8 2, 3, 4, 5, 7, 8 314 314 314
30HXC076---1 1, 2, 3, 4, 5, 6 — 1, 2, 3, 4, 5, 6 56 — 56
30HXC076---2 1, 2, 3, 5, 6, 7 — 1, 2, 3, 5, 6, 7 84 — 84
30HXC076---3 1, 2, 3, 5 — 1, 2, 3, 5 96 — 96
30HXC076---5 1, 2, 5, 7, 8 — 1, 2, 5, 7, 8 154 — 154
30HXC076---6 1, 2, 3, 4, 6, 8 — 1, 2, 3, 4, 6, 8 70 — 70
30HXC076---8 1, 2, 4 — 1, 2, 4 144 — 144
30HXC076---9 1, 2, 3, 5, 6 — 1, 2, 3, 5, 6 88 — 88
30HXC086---1 1, 2, 3, 4, 6, 7 — 1, 2, 3, 4, 5, 6 68 — 56
30HXC086---2 1, 2, 3, 6, 8 — 1, 2, 3, 5, 6, 7 102 — 84
30HXC086---3 1, 2, 4, 5, 6, 7 — 1, 2, 3, 5 116 — 96
30HXC086---5 1, 3, 4, 5, 7, 8 — 1, 2, 5, 7, 8 186 — 154
30HXC086---6 1, 2, 3, 5, 6, 7 — 1, 2, 3, 4, 6, 8 84 — 70
30HXC086---8 1, 2 — 1, 2, 4 176 — 144
30HXC086---9 1, 2, 3, 7, 8 — 1, 2, 3, 5, 6 106 — 88
30HXC096---1 1, 2, 3, 5, 6, 7, 8 — 1, 2, 3, 4, 5, 6 82 — 56
30HXC096---2 1, 2, 4, 5, 7 — 1, 2, 3, 5, 6, 7 124 — 84
30HXC096---3 1, 2, 4, 7 — 1, 2, 3, 5 140 — 96
30HXC096---5 1, 3, 6, 7, 8 — 1, 2, 5, 7, 8 226 — 154
30HXC096---6 1, 2, 3, 6 — 1, 2, 3, 4, 6, 8 104 — 70
30HXC096---8 1, 3, 5, 6, 7 — 1, 2, 4 212 — 144
30HXC096---9 1, 2, 4, 5 — 1, 2, 3, 5, 6 128 — 88
30HXC106---1 1, 2, 3, 6, 7 — 1, 2, 3, 4, 5, 6 100 — 56
30HXC106---2 1, 2, 5, 6, 8 — 1, 2, 3, 5, 6, 7 150 — 84
30HXC106---3 1, 2, 6 — 1, 2, 3, 5 168 — 96
30HXC106---5 1, 5, 6, 7, 8 — 1, 2, 5, 7, 8 274 — 154
30HXC106---6 1, 2, 4, 5, 7 — 1, 2, 3, 4, 6, 8 124 — 70
30HXC106---8 1, 4, 5, 8 — 1, 2, 4 254 — 144
30HXC106---9 1, 2, 5, 7, 8 — 1, 2, 3, 5, 6 154 — 88
30HXC116---1 1, 2, 3, 6, 7 — 1, 2, 3, 4, 6, 7 100 — 68
30HXC116---2 1, 2, 5, 6, 8 — 1, 2, 3, 6, 8 150 — 102
30HXC116---3 1, 2, 6 — 1, 2, 4, 5, 6, 7 168 — 116
30HXC116---5 1, 5, 6, 7, 8 — 1, 3, 4, 5, 7, 8 274 — 186
30HXC116---6 1, 2, 4, 5, 7 — 1, 2, 3, 5, 6, 7 124 — 84
30HXC116---8 1, 4, 5, 8 — 1, 2 254 — 176
30HXC116---9 1, 2, 5, 7, 8 — 1, 2, 3, 7, 8 154 — 106
1
8
