APPENDIX A
Compressor Protection Module Configuration Header Punch-Outs and Must Trip Amps
UNIT
MODEL
NUMBER
PUNCH OUTS
FOR
COMP A1
PUNCH OUTS
FOR
COMP A2
PUNCH OUTS
FOR
COMP B1
COMP A1
MUST TRIP AMPS
SETTING
COMP A2
MUST TRIP AMPS
SETTING
COMP B1
MUST TRIP AMPS
SETTING
30GX-080---1 1, 2, 3, 6, 7, 8 — 1, 2, 3, 5, 6, 7, 8 98 — 82
30GX-080---2 1, 2, 5, 6 ,7 — 1, 2, 4, 5 ,7 148 — 124
30GX-080---5 1, 4, 8 — 1, 3, 6, 7, 8 270 — 226
30GX-080---6 1, 2, 4, 5, 7, 8 — 1, 2, 3, 6, 8 122 — 102
30GX-080---8 1, 4, 5 — 1, 3, 5, 6, 7 256 — 212
30GX-080---9 1, 2, 6, 7 — 1, 2, 4, 5 156 — 128
30GX-090---1 1, 2, 4, 5, 6 — 1, 2, 3, 5, 6, 7, 8 120 — 82
30GX-090---2 1, 3, 4, 5, 6, 7 — 1, 2, 4, 5, 7 180 — 124
30GX-090---5 2, 3, 4, 6 — 1, 3, 6, 7, 8 328 — 226
30GX-090---6 1, 2, 5, 6, 7 — 1, 2, 3, 6, 8 148 — 102
30GX-090---8 2, 3, 4, 5, 6, 8 — 1, 3, 5, 6, 7 310 — 212
30GX-090---9 1, 3, 4, 5, 7 — 1, 2, 4, 5 188 — 128
30GX-105---8 2, 3, 5, 6 — 1, 3, 8 344 — 238
30GX-105---9 1, 3, 4 — 1, 2, 4 208 — 144
30GX-106---1 1, 2, 4, 6, 8 — 1, 2, 3, 5, 7 134 — 92
30GX-106---2 1, 3, 4, 7, 8 — 1, 2, 4, 7 202 — 140
30GX-106---5 2, 3 — 1, 4, 5, 8 368 — 254
30GX-106---6 1, 2, 6 — 1, 2, 4, 5, 6, 7, 8 168 — 114
30GX-106---8 2, 3, 5, 6 — 1, 3, 8 344 — 238
30GX-106---9 1, 3, 4 — 1, 2, 4 208 — 144
30GX-115---1 1, 2, 6, 7, 8 — 1, 2, 3, 5, 7 162 — 92
30GX-115---2 1, 4, 5, 6, 8 — 1, 2, 4, 7 246 — 140
30GX-115---5 3, 4, 5 — 1, 4, 5, 8 448 — 254
30GX-115---6 1, 3, 4, 7 — 1, 2, 4, 5, 6, 7, 8 204 — 114
30GX-115---8 2, 6, 7, 8 — 1, 3, 8 418 — 238
30GX-115---9 1, 4, 5, 8 — 1, 2, 4 254 — 144
30GX-125---1 1, 2, 6, 7, 8 — 1, 2, 3, 8 162 — 110
30GX-125---2 1, 4, 5, 6, 8 — 1, 2, 6 246 — 168
30GX-125---5 3, 4, 5 — 2, 3, 4, 5, 6, 7, 8 448 — 306
30GX-125---6 1, 3, 4, 7 — 1, 2, 4, 7, 8 204 — 138
30GX-125---8 2, 6, 7, 8 — 1, 5 418 — 288
30GX-125---9 1, 4, 5, 8 — 1, 2, 8 254 — 174
30GX-136---1 1, 2, 6, 7, 8 — 1, 2, 4, 6, 8 162 — 134
30GX-136---2 1, 4, 5, 6, 8 — 1, 3, 4, 7, 8 246 — 202
30GX-136---5 3, 4, 5 — 2, 3 448 — 368
30GX-136---6 1, 3, 4, 7 — 1, 2, 6 204 — 168
30GX-136---8 2, 6, 7, 8 — 2, 3, 5, 6 418 — 344
30GX-136---9 1, 4, 5, 8 — 1, 3, 4 254 — 208
30GX-150---8 2, 3, 5, 6 — 4, 6 344 — 520
30GX-150---9 1, 3, 4 — 2, 3, 4, 5, 7, 8 208 — 314
30GX-151---1 1, 3, 4, 6, 8 — 1, 2, 4, 6, 8 198 — 134
30GX-151---2 1, 7 — 1, 3, 4, 7, 8 300 — 202
30GX-151---5 6, 7, 8 — 2, 3 546 — 368
30GX-151---6 1, 4, 5, 6 — 1, 2, 6 248 — 168
30GX-160---8 2, 6, 7, 8 — 4, 6 418 — 520
30GX-160---9 1, 4, 5, 8 — 2, 3, 4, 5, 7, 8 254 — 314
30GX-161---1 1, 3, 4, 6, 8 — 1, 2, 6, 7, 8 198 — 162
30GX-161---2 1, 7 — 1, 4, 5, 6, 8 300 — 246
30GX-161---5 6, 7, 8 — 3, 4, 5 546 — 448
30GX-161---6 1, 4, 5, 6 — 1, 3, 4, 7 248 — 204
30GX-161---8 4, 6 — 2, 6, 7, 8 520 — 418
30GX-161---9 2, 3, 4, 5, 7, 8 — 1, 4, 5, 8 314 — 254
30GX-175---8 4, 6 — 4, 6 520 — 520
30GX-175---9 2, 3, 4, 5, 7, 8 — 2, 3, 4, 5, 7, 8 314 — 314
30GX-176---1 1, 3, 4, 6, 8 — 1, 3, 4, 6, 8 198 — 198
30GX-176---2 1, 7 — 1, 7 300 — 300
30GX-176---5 6, 7, 8 — 6, 7, 8 546 — 546
30GX-176---6 1, 4, 5, 6 — 1, 4, 5, 6 248 — 248
1
8
