Carrier Ecologic Series 3 - Page 22

22
Table 13 — Status Function and Subfunction Directory (cont)
See Legend on page 25.
SUBFUNCTION KEYPAD ENTRY DISPLAY COMMENT
5 Circuit B Analog Values (cont)
B1 Motor Temperature
xxx.x dF
B2 Motor Temperature
xxx.x dF
SAT Condensing Temp
xxx.x dF
Saturated Suction Temp
xxx.x dF
EXV Percent Open
xxx.x%
Motormaster Speed
xxx.x%
Water Valve Position
xxx.x%
Cooler Level Indicator
x.xx
CPM B1 Feedback
x.x Volts
CPM B2 Feedback
x.x Volts
Circuit B Econ Pressure
xxx.x PSI
See Table 5.
See Table 5.
6 Circuit B Discrete Inputs/Outputs
CIR. B DISCRETE OUTPUTS
Compressor B1
Off/On
Compressor B2
Off/On
Loader B1
Off/On
Loader B2
Off/On
Minimum Load Valve B
Off/On
Circuit B Oil Heater
Off/On
B1 Mtr Cooling Solenoid
Off/On
B2 Mtr Cooling Solenoid
Off/On
Circuit B Oil Pump
Off/On
Oil Solenoid B1
Off/On
Oil Solenoid B2
Off/On
CIR. B DISCRETE INPUTS
Circuit B Oil Switch
Open/Close
Compressor B1 Feedback
Off/On
Compressor B2 Feedback
Off/On
7 Unit Analog Parameters
UNITS ANALOG PARAMETERS
Cooling Entering Fluid
xx.x dF
Cooling Leaving Fluid
xx.x dF
Condenser Entering Fluid
xx.x dF
Condenser Leaving Fluid
xx.x dF
Reclaim Entering Fluid
xx.x dF
Reclaim Leaving Fluid
xx.x dF
5 Volt Supply
x.x Volts
