i-Vu® XT Router (drv_gen5) CARRIER CORPORATION ©2022
Installation and Start-up Guide 26 All rights reserved
Number of seconds to wait for a hub to reply to a connection request.
Number of seconds to wait for a hub to reply to a disconnect request.
Initiating Heartbeat Interval
Number of seconds to wait to send a heartbeat.
Accepting Heartbeat Interval
Number of seconds to wait to receive a heartbeat.
See "To create or replace a BACnet/SC device’s operational certificate" in the
BACnet/SC Setup Guide for instructions on how to create the router’s operational
certificate, signed by the BACnet/SC network’s Certificate Authority.
Enable for a BACnet/MSTP network.
Auto Generate Network
Number
If checked, network number is autogenerated, which then automatically sets to
((IP network number + rotary switch address) x 10) + 0.
Uncheck to use Custom Static Address Mode.
The network number is 0 by default. Filled in automatically if Autogenerate
Network Number is checked.
NOTE When downloaded from the i-Vu® application, these numbers match those
set using SiteBuilder.
You set the address for Port S1, which must be unique for the system.
Indicates status of the router's End of Net? switch.
To increase MS/TP performance, enter the highest address used on the MS/TP
network for a master controller. This number must be less than or equal to 127.
This is the maximum number of information messages a controller may transmit
before it must pass the token to the next controller. Valid values are 1 to 255.
TIP Set Max Info Frames to a number in the range 20 to 100 so that the
router does not become a bottleneck for traffic being routed from a high-speed
network to the slower MS/TP network.
The maximum length of a message or message segment that can be accepted by
the BACnet device.
Set this to a baud rate that all other devices on the MS/TP network are set to.
Select 9600, 19200, 38400, 57600, 76800, or 115200.
