Installation & Commissioning Manual:
Neos 100S, 20X, 30S, 35X, 40X, 50X
62-11165 Rev D
®
13
Refrigerant Hose Installation – Installation Preparation
Always use the required tools as follows:
Hose Cutting / Crimping Kit: 07-60117-00
Fitting Insertion Tool: 07-60177-00
Cut the hose to the required length using
the Carrier hose cutting tool.
Lubricate the inside of the hose end with
POE oil.
Widen the internal hose clearance using
the expanding tool before sliding the
double zinc clamp over the hose.
