Carrier Integra 40X - Condenser Installation - Front Mount Application

Installation & Commissioning Manual:
Neos 100S, 20X, 30S, 35X, 40X, 50X
62-11165 Rev D
®
7
Condenser Installation – Front Mount Application
NEOS 100S, 20X
24.41” (620)
5.12”
(130)
2.36”
(60)
2.36” (60)
Ø 3.50”
(Ø 90)
4 x Ø 0.56”
(4 x Ø 15)
Ø 4.0”
(Ø 100)
4 x Ø 0.56”
(4 x Ø 15)
33.66” (855)
12.75”
(324)
4.33”
(110)
2.17”
(55)
Front Mount Applications: Mark and drill the four condenser mounting holes, as well as the
larger refrigerant and electrical pass-thru hole, as indicated above (depending on unit model)
Bolt the condensing unit in place using the hardware supplied in the mounting kit.
30S
40X
50X
44.1” (1,120)
12.6”
(320)
4 x Ø 0.63”
(4 x Ø 16)
Ø 4.0”
(Ø 100)
1.18”
(30)
21.26”
(540)
22.05” (560)
5.31” (135)
6” MIN to
cab roof
35X
