High Wall Type
Owner’s Manual
–8–
EN
4. Accessories
5. Part Names
Indoor unit
1 Room temperature sensor
2 Front panel
3 Return air grille
4 Air filter
5 Air discharge
6 Horizontal airflow louver
7 Vertical airflow louver
8 Display panel
9 Infrared signal receiver
10Remote control (wireless)
11Remote control (wired, sold separately)
Wireless Remote control Remote control holder Batteries (two)
SET
TIME
TIMER SET
TEST
FILTER
RESET
CL
FAN
SAVE
SWING/FIX
VENT
MODE
UNIT LOUVER
11
10
7
8, 9
6
5
3
4
1
2
