Carrier PHJ4 - A10380; Fig. 11 - Single Point Connections For Heaters Without Circuit Breakers; A10379; Fig. 12 - Dual Point Connections For Heater With Circuit Breaker

Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
10
A10380
Fig. 11 – Single Point Connections For Heaters Without Circuit Breakers
A10379
Fig. 12 – Dual Point Connections For Heater With Circuit Breaker
A10382
Fig. 13 – Dual Point Connections For Heaters Without Circuit Breakers
POWER LINE
TO HEATER
24V FIELD
WIRING BOX
THE SECOND FIELD
POWER LINE TO UNIT
CONTACTOR
FIRST FIELD POWER
LINE TO HEATER
24V FIELD
WIRING BOX
24V FIELD
WIRING BOX
SECOND FIELD
POWER LINE TO
UNIT CONTACTOR
FIRST FIELD
POWER LINE
TO HEATER
