Carrier PHJ4 - A10031; Fig. 5 - Unit Control Box Compartment; A10119; Fig. 6 - Heater Control Panel Installation

Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
6
A10031
Fig. 5 – Unit Control Box Compartment
A10119
Fig. 6 – Heater Control Panel Installation
Electric Heat wiring
interconnection (electric
heater controls removed
for clarity)
Electric Heat Control Box
(shown uninstalled)
HEATER CONTROL PANEL
MOUNTING SCREWS (4)
