Start-up
UPC Open Carrier Proprietary and Confidential CARRIER CORPORATION ©2017
Installation and Integration Guide All rights reserved
15
Consider the following before creating your program in Snap:
• Is the equipment already available in EquipmentBuilder?
• Which points from the Carrier equipment are to be mapped in the UPC Open?
• What type of Carrier microblock does each point require?
• Do you need to create custom Property pages for the equipment?
• Are there any special microblocks you may need, such as Communication Device, Schedule, Alarms?
To create your control program in Snap, you must:
• Obtain your CCN points list from the equipment or CCN database.
• Know what points need to be mapped in the control program to the equipment.
•
Load a separate control program if Airside Linkage is needed and the UPC Open is used on a rooftop unit. An
Airside Linkage equipment file can be selected in EquipmentBuilder.
After creating your control program, you can create a custom graphic using ViewBuilder. See To install the UPC
Open into an i-Vu® Control System (page 15) to load your control program and graphic into the controller.
To install the UPC Open into an i-Vu® Control System
You must complete the following procedures to successfully install your UPC Open into an i-Vu® Control System.
Use the Help in the referenced software for detailed descriptions of these procedures.
EquipmentBuilder or Snap
1 Use EquipmentBuilder or Snap to create control program(s) for your UPC Open.
2 If applicable, print the Sequence of Operation, which includes the points list.
NOTE You can create a points list under Reports in the i-Vu® application or Field Assistant after installing
your control program.
The i-Vu® or Field Assistant application
1 Upload the controller to the database by selecting the router in the navigation tree.
2 Select Devices > Manage tab.
3 Select the controller in the list on the page.
4 If you are adding a new control program, click . A dialog window appears.
5 Enter a name for your control program in Display Name and select your controller in the Controller drop-down
list.
NOTES
○ If you already have the maximum number of control programs for a controller, it will not appear in the
list.
○ Optional: You can change the control program's Reference Name if needed.
